CFC Free R410a Refrigerant Details (Properties and Data Sheet)

As a medium and high temperature refrigerant widely used today, R-410A freon gas is eco friendly mainly used in household air conditioners, small and medium commercial air conditioners. You can always contact us for latest cost and price of R410a refrigerant.
Quantity:
  • Ningbo, China
  • USD28 - USD 50
  • 100 bottles
  • L/C, T/T
  • 11.3KG Disposable Cylinder or Others
  • 2.2
  • 50% of R32 and 50% of R125
  • 75-10-5 & 354-33-6
  • 3163

CFC Free R410a Refrigerant Details (Properties and Data Sheet)Please contact us on data sheet of R410a refrigerant gas.

11.3KG R410A Certification:DOT/KGS/CE

The table shows details of R410a refrigerant gas.
Cylinder Height Diameter Thickness
420mm 241mm 1.5mm
Material Capacity Weight
DC01 13.3L 3.5kg
Working Pressure Testing Pressure Filling Gas
2.8Mpa 3.45Mpa R410A/R32
Gas Purity 99.91%-99.97%
Gas N.W. 11.3KG/25lb
Packing carton size 24.5*24.5*42.5cm
Packing, Payment and Delivery
Packing 1 cylinder/carton, disposable cylinder,neutral graphic design packing
Loading 1140 cylinders/20ft container
Payment Normally By T/T 30% as deposit, and the 70% balance against copy of B/L
Delivery within 20 days after receipt of deposit and confirm of carton design
Find details of all kinds of refrigerant gas on frioflor brand


The capacity and pressure of R410A are higher than R22, and the operating pressure is 50%-60% higher. As a result of high pressure and high gas density, not only can compressors with smaller displacements be used, but also smaller diameter pipes and valves can be used. The use of high-pressure exhaust valve eliminates the hidden dangers caused by the high pressure of system condensation. The thick compressor casing allows the system to withstand higher operating pressures. Another advantage of making the compressor thicker is that the operating noise of R410A is significantly lower than that of R22 compressor by 2-4 decibels.


Compared with the R22 system, the R410A system has a significant heat transfer advantage-the heat transfer of the evaporator is 35% higher, and the condenser is 5% higher. The system heat transfer coefficients of R134a and R407C are lower than R22. Under the same mass flow, the pressure drop of R410A is small, making it possible to use smaller pipelines and valves than R22 or other refrigerants.


R410A refrigerant composition: R32, R125

Mole percentage: R32 accounts for 70%, R125 accounts for 30%

Mass percentage: R32 accounts for 50%, R125 accounts for 50%


UN NO:3163

CAS NO: 354-33-6,75-10-5


Refrigerant Freon Workshop and Shipment Glance
Contact us for cost of CFC Free R410a refrigerant gas.
